Dimensions
Max Height4281mm
Min Position-1700mm
Maximum reach3253 mm
Base Dimensions950*919mm
Base Height610mm
Working Volume79.86m³
'/%3e%3cpath%20d='M550.68,115.88l42.78-50h34.66L567.87,136.1l59.86,69.82H593.26l-42.58-49.61L508.3,205.92H473.73L533.5,136.1l-60-70.22h34.38Z'%20transform='translate(0.11%200)'/%3e%3cpath%20d='M770.7,91.27h-56V205.92h-25.4V91.27H633.3V65.88H770.7Z'%20transform='translate(0.11%200)'/%3e%3c/svg%3e)
U-MOCO EXT Cinematic Robotic Arm
Extreme Reach, Expanding Creative Boundaries
016m wingspan for expansive creative freedom
024m vertical reach for overhead angle capture
03From close-up to wide shot, one machine does it all
04Track-compatible for unlimited camera range
Specifications
Core dimensions, motion performance, and operating environment
Axis Limits
A1±185°
A2-175°～+60°
A3-120°～+170°
A4±350°
A5±130°
A6±350°
Performance
Maximum rotational linear speed9.5 m/s
Stable speed2 m/s
Maximum linear speed4 m/s
Rated payload20 kg
System weight (configuration dependent)≈958 kg
Repeatability±0.05 mm
Power & Environment
Power input380 V
Input current20 A
IP RatingIP65
Operating temperature0–55 °C
Annotated Diagram
